JAH – 1000H at 105°C, Axial Aluminum Electrolytic Capacitors, Standard Low Voltage
The JAH series axial aluminum electrolytic capacitors are engineered for general-purpose, low voltage applications. With a load life of 1000 hours at 105°C, they offer reliable performance in compact designs.
Available with two rubber sealing types and compliant with RoHS directives, these capacitors are ideal for cost-effective and space-saving circuit solutions.
Description
Specifications
Specifications
| Items | Performance Characteristics |
|---|---|
| Operating Temperature Range (°C) | -40℃~+105℃ |
| Capacitance Tolerance (20°C, 120Hz) | ±20% |
| Leakage Current (mA) | I ≤ 0.02CV or 3 (µA) Whichever is greater (after 2 minutes applying the rated DC working Voltage at 20 ℃) |
Drawing
