jb Capacitors Company Offer Small Size SMD Capacitors
To meet the demands of the market, we launched two series of SMD capacitors. One is JCT, the other one is JCX. Both series can be used on general application.
It can be used on the board with space economic. If you have demands in small size SMD Aluminum Electrolytic capacitors, you can try this for your electronic board.
Also, they have different load life range. JCX has wider load life range from 2000H to 5000H. JCT has 2000H to 3000H. Both series has almost the same features, the biggest difference is their load life.
JCT – 2000H to 3000H at 105°C, Small Size SMD Aluminum Electrolytic Capacitor
JCX – 2000H to 5000H at 105°C, Small Size SMD Aluminum Electrolytic Capacitor
| Operating Temperature | -55°C~ +105°C |
| Voltage Range | 6.3V ~ 50V.DC |
| Capacitance Range | 10 ~ 2200μF |
| Capacitance Tolerance | ±20% at 120Hz, 20°C |
| Leakage Current | The greater value of either 0.01CV or 3μAr μA/after 2minutes (max) |
Selection Guide
When choosing small-size surface-mount components, use the following guide for jb Capacitors Company’s SMD offerings:
- JCT Series: Small size SMD aluminum electrolytic capacitor designed for space-economic electronic boards, rated for 2000H to 3000H at 105°C.
- JCX Series: Small size SMD aluminum electrolytic capacitor built with a wider load life range from 2000H to 5000H at 105°C.
- Application Fit: Both series share almost identical features and general application suitability, allowing you to choose based on your specific load life requirements.
Application
The jb Capacitors Company Offer Small Size SMD Capacitors (JCT and JCX series) are engineered for modern electronic assemblies where space economy is critical:
- General application electronic circuit boards
- Compact consumer electronics and power supply units
- Space-constrained PCB layouts requiring reliable surface-mount aluminum electrolytic capacitors
Frequently Asked Question (FAQ)
- Q: What are the two SMD capacitor series offered by jb Capacitors? A: The two series are JCT and JCX, both designed as small-size SMD aluminum electrolytic capacitors for general applications.
- Q: What is the main difference between the JCT and JCX series? A: While they share almost identical features, the biggest difference is their load life range: JCX offers a wider load life of 2000H to 5000H at 105°C, whereas JCT provides 2000H to 3000H at 105°C.
- Q: Where should these capacitors be used? A: They are ideal for electronic boards requiring space economy and compact surface-mount solutions.
