JBR-BQ Wirewound Resistor

JBR-BQ Wirewound Resistors deliver stable and accurate resistance values across a wide range of 0.01Ω to 82KΩ. Rated from 3W up to 500W, they are ideal for industrial and high-power electronics requiring consistent thermal performance.

With precision tolerance options of ±1% and optional heat sinks for better dissipation, the JBR-BQ series is built to handle demanding conditions while maintaining high efficiency and reliability.

Features

Power Rating: 3W to 500W
Resistance Range: 0.01Ω to 82KΩ
Tolerance: ±1%, ±5%
Temperature Coefficient of Resistance (TCR): ±100, ±50 ppm/°C
High Voltage Rating: Up to 2000V
Durable Design: Available with or without heat sink for enhanced heat dissipation.

Power Rating	3W to 500W
Resistance Range	0.01Ω to 82KΩ
Tolerance	±1%, ±5%
Temperature Coefficient of Resistance (TCR)	±100, ±50 ppm/°C
Voltage Rating	Up to 2000V

Power Rating

3W to 500W

Resistance Range

0.01Ω to 82KΩ

Tolerance

±1%, ±5%

Temperature Coefficient of Resistance (TCR)

±100, ±50 ppm/°C

Voltage Rating

Up to 2000V
